Android 5.1 Lollipop: multi-SIM and anti-theft

Android 5.1 is a small update to Lollipop with its own API level. For users it brought more than one SIM card in one phone, Device Protection, which keeps a stolen phone locked after a factory reset, and HD voice calls. For developers it added SubscriptionManager, a way for carrier apps to hold special privileges, and a deprecation notice for the Apache HTTP client.

The rest of Lollipop arrived in 5.0 and is covered in the Android 5.0 Lollipop note. This note covers only what 5.1 added.

At a glance

Google announced 5.1 on its Android blog on 9 March 2015 and said it was “rolling out” without naming devices. The next day the developer blog published the SDK and listed the Nexus 4, 5, 6, 7, 9, 10 and Nexus Player for updates over the next few weeks. The first AOSP build, LMY47D (android-5.1.0_r1), covers the Nexus 5, 6, 7 (2012), 10 and Nexus Player. Android 5.1.1 builds followed under the same API level.

Android 5.1.1 reached AOSP on 21 April 2015 as LMY47V (android-5.1.1_r1), first for the Nexus 7, Nexus 10 and Nexus Player. It mattered for the memory leak that users had reported since 5.0: Android Police found the leak still present in 5.1, Google said on its issue tracker that it was “fixed internally”. When 5.1.1 reached AOSP, Android Police wrote that Google claimed a fix for a significant memory leak in it. The last 5.1.1 build, LMY49M (android-5.1.1_r38), went to the Nexus 10 with the 5 July 2016 security patch level.

Before the announcement, Google’s Android One site for Indonesia listed 5.1 on the spec sheets of phones from Evercoss, Mito and Nexian. Android Police reported it on 4 February 2015, and Ars Technica called it a premature launch. Google’s own post on Android One in Indonesia says only “Lollipop”.

What it brought

Google’s own description of 5.1 was an update that “improves stability and performance”, plus a few new features. Ars Technica read it the same way: a minor update.

• Multiple SIM cards. A device with two or more SIM slots can use more than one carrier SIM at a time. The developer blog calls it important for the regions where Android One phones were being adopted.
• Device Protection. A lost or stolen device stays locked until someone signs in with the owner’s Google account, even after a factory reset. Covered under security below.
• HD voice. High-definition calls between compatible 5.1 devices, such as the Nexus 6 on T-Mobile or Verizon.
• Quick Settings. Users can join a Wi-Fi network and control paired Bluetooth devices from Quick Settings.
• Android for Work. The developer blog says 5.1 “enhances enterprise features” for the Android for Work launch. The API diff shows DevicePolicyManager#setTrustAgentConfiguration(), provisioning extras such as EXTRA_PROVISIONING_ACCOUNT_TO_MIGRATE, and the UserManager.DISALLOW_OUTGOING_BEAM restriction.

For developers, the API page lists only three topics: multiple SIMs, carrier services and the deprecated HTTP classes. The API diff adds smaller pieces:

• SubscriptionManager, with SubscriptionInfo and OnSubscriptionsChangedListener. getActiveSubscriptionInfoList() returns the active SIMs, and isNetworkRoaming(subId) tells you if one is roaming, so an app can cut data use for that SIM.
• Per-SIM SMS. SmsManager.getSmsManagerForSubscriptionId() sends from a chosen SIM.
• Carrier services, in the new android.service.carrier package and in TelephonyManager and SmsManager. See below.
• Activity#getReferrer(), which returns who launched the activity, either Intent.EXTRA_REFERRER or an android-app: URI with the caller’s package.
• Intent.createChooser() with an IntentSender, which tells your app which target the user picked (EXTRA_CHOSEN_COMPONENT).
• Smaller additions. KeyguardManager#isDeviceLocked(), ConnectivityManager#requestNetwork() with a PendingIntent, VpnService.Builder#setUnderlyingNetworks() and Settings.ACTION_BATTERY_SAVER_SETTINGS.

Carrier privileges

A carrier app gets access to protected telephony APIs when its signing certificate matches an access rule stored on the SIM card (UICC). The rule holds the SHA-1 or SHA-256 hash of the certificate, and optionally a package name. Android reads it from the access rule application (ARA) on the card, or from the access rule file (ARF) if there is none.

With privileges, an app can call TelephonyManager#setOperatorBrandOverride(), setVoiceMailNumber() and setLine1NumberForDisplay(), and run a CarrierMessagingService that the system calls for SMS and MMS. Google’s point was that such apps can be distributed through Google Play. Check with hasCarrierPrivileges() before calling: without privileges, these calls throw a SecurityException.

Security and privacy

• Device Protection (factory reset protection). After a reset, setup asks for the Google account that was on the device. Google said it would be on “most Android phones and tablets shipped with Android 5.1”, plus the Nexus 6 and Nexus 9. The storage behind it, PersistentDataBlockService, is already in the 5.0 AOSP source.
• Wiping the protection. API 22 adds DevicePolicyManager.WIPE_RESET_PROTECTION_DATA, a flag for wipeData() that also erases the factory reset protection data. Only a device owner may set it; any other admin gets a SecurityException.
• Encryption. The 5.1 CDD requires full-disk encryption support on devices with a PIN or password lock screen, but turning it on by default is still a SHOULD, “very strongly RECOMMENDED” and expected to become a MUST. The 6.0 CDD made it a MUST for devices with fast enough AES.
• Verified Boot is also a SHOULD in the 5.1 CDD. When a device supports it, verification must start from a hardware root of trust and reach the system partition, with SHA-256 and RSA-2048 at least.
• Smaller CDD changes. If multiple users are on and the primary external storage is removable, the SD card must be encrypted. A preloaded VPN or proxy that routes traffic by default needs the user’s consent first.

Google’s “Security enhancements by release” page has sections for 5.0 and 6.0, but none for 5.1.

Permissions

Android 5.1 keeps 5.0’s model: every permission is granted at install. Runtime permissions came in Android 6.0.

• Added. BIND_CARRIER_MESSAGING_SERVICE, which protects a CarrierMessagingService so that only the system can bind to it.
• READ_PHONE_STATE is what an app needs to read active SIMs and to register OnSubscriptionsChangedListener.
• Carrier privileges are not a manifest permission. The SIM card grants them by certificate, as described above.

What changed for your app

All apps on Android 5.1

Apps targeting API 22

Google published no list of behaviour changes for apps targeting API 22. The 5.1 API page covers new APIs and the HTTP deprecation only. The LOLLIPOP_MR1 constant in AOSP carries a one-line joke instead of the change list that LOLLIPOP has (see below).

What lasted

• Apache HTTP left the SDK in Android 6.0 and the bootclasspath in Android 9. The Android 6.0 note has the useLibrary 'org.apache.http.legacy' workaround.
• SubscriptionManager is still the multi-SIM API. from(Context) was deprecated in API 28 in favour of getSystemService(), and from SDK 35 getActiveSubscriptionInfoList() never returns null.
• Carrier privileges grew. API 23 added CarrierConfigManager and replaced BIND_CARRIER_MESSAGING_SERVICE with BIND_CARRIER_SERVICES. Today the same UICC rules cover SubscriptionManager, EuiccManager, network stats and more.
• Device Protection is still there. Google’s help today says a reset device asks for “any Google Account previously added and synced to the device”, and cannot be used without it.
• Google Play services stopped updating on Lollipop (API 21 and 22) in July 2024. Google said Lollipop was under 1% of active devices; Play services updates now need Android 6.0 (API 23). Apps that depend on new Play services features cannot count on them below API 23.
• Fire OS 5, Amazon’s fork, is based on Android 5.1 at API level 22. It runs on Fire TV models released from 2014 to 2017, so an app that supports them needs a minSdkVersion of 22 or lower.

Worth knowing

• The AOSP comment on LOLLIPOP_MR1 reads: Lollipop with an extra sugar coating on the outside! That is the whole Javadoc.
• The Easter egg is still L Land, the tap-to-fly game from 5.0. In 5.1 it vibrates for 80 ms when you hit an obstacle or the floor, except in silent mode. The code says: No interruptions. Not even game haptics.
• The 5.1 game also gained a hidden switch, DEBUG_IDDQD, read from the LLand.iddqd log tag. With it on, obstacles no longer end the game and the score shows ??. In 5.0 it was hard-coded off.
